CA. IR. COV. C250 FSØ160 COØ160 DWA/EU COPRO NDLV
CA. IR. COV. C250 FSØ160 COØ160 DWA/EU COPRO NDLV
| Code | DWA160F |
| Code | DWA160F |
| Reference | 49847 |
| Unit | pieces |
| Product model | Cast Iron Manhole Cover |
| Availablility |
Availablility
|
| Description |
A hinged hydraulic connection cover, load class C250. |
| Documents |
Availablility
-
Hamme
-
Oostakker
A hinged hydraulic connection cover, load class C250.
Become a professional online customer
- ✓ Access to your net prices
- ✓ Exclusive online promotions
- ✓ Tracking of your orders, deliveries, and invoices
- ✓ Insight into the currently available stock per branch
- ✓ 1% additional online order discount on top of your net prices
Product information
(Well informed)Description
(In detail)
A hinged hydraulic connection cover, load class C250.
Application
Intended for pedestrian zones, car parks and similar areas with vehicle traffic.
Pros and cons
(According to our consultants)Technical specifications
(Everything you should know)| Product type | Cast Iron Manhole Cover |
| Width (mm) | 295mm |
| Length (mm) | 295mm |
| Load class | C250 |
| Shape | Square |
| Certificate | Copro |
| Raw material | Cast iron |
| Certificate norm | EN 124-2 |
| Weight (kg) | 9kg |
| Height (mm) | 91mm |
| Lid properties | Hydraulic seal, Hinged cover |
| Clear opening diameter Ø (mm) | 160mm |
| Label | DWA |
