GALVANIZED MESH GRATE 900X900 CS30/2

GALVANIZED MESH GRATE 900X900 CS30/2

Code MAZ090090302
Code MAZ090090302
Reference 19602
Unit pieces
Product model Mesh grille galvanized
Availablility

Availablility

Description

Deschacht works in collaboration with a German manufacturer and offers a range of the most commonly requested standard grating panels. In addition, custom-made gratings can be produced with acceptable lead times. These gratings are available in heights from 20 to 60 mm, with load-bearing bars in thicknesses of 2 or 3 mm and a frame thickness of 2 to 3 mm. Mesh spacing is available in multiples from 11 mm up to 99 mm and can, if required, differ in the direction of the load-bearing bars and the cross bars. Anti-slip can be applied to the cross bars, the load-bearing bars, or both. Furthermore, specific versions are available for pallet racking. Various additional welding options are also possible, such as toe plates, cut-outs according to drawing, and the fitting of hinges.

Full description
Documents

Availablility

Deschacht works in collaboration with a German manufacturer and offers a range of the most commonly requested standard grating panels. In addition, custom-made gratings can be produced with acceptable lead times. These gratings are available in heights from 20 to 60 mm, with load-bearing bars in thicknesses of 2 or 3 mm and a frame thickness of 2 to 3 mm. Mesh spacing is available in multiples from 11 mm up to 99 mm and can, if required, differ in the direction of the load-bearing bars and the cross bars. Anti-slip can be applied to the cross bars, the load-bearing bars, or both. Furthermore, specific versions are available for pallet racking. Various additional welding options are also possible, such as toe plates, cut-outs according to drawing, and the fitting of hinges.

Full description
Become a professional online customer
  • Access to your net prices
  • Exclusive online promotions
  • Tracking of your orders, deliveries, and invoices
  • Insight into the currently available stock per branch
  • 1% additional online order discount on top of your net prices

Product information

(Well informed)

Description

(In detail)

Deschacht works in collaboration with a German manufacturer and offers a range of the most commonly requested standard grating panels. In addition, custom-made gratings can be produced with acceptable lead times. These gratings are available in heights from 20 to 60 mm, with load-bearing bars in thicknesses of 2 or 3 mm and a frame thickness of 2 to 3 mm.

Mesh spacing is available in multiples from 11 mm up to 99 mm and can, if required, differ in the direction of the load-bearing bars and the cross bars.

Anti-slip can be applied to the cross bars, the load-bearing bars, or both. Furthermore, specific versions are available for pallet racking. Various additional welding options are also possible, such as toe plates, cut-outs according to drawing, and the fitting of hinges.

Pros and cons

(According to our consultants)
  • Materials used in accordance with EN 10.025
  • ST37-2 or S235JR (DIN 17.100); FE 360B
  • Manufactured in accordance with DIN 24.537
  • Hot-dip galvanised in accordance with EN ISO 1461 (DIN 50976)

Technical specifications

(Everything you should know)
Product type Mesh grille galvanized
Height (mm) 30mm
Width (mm) 900mm
Length (mm) 900mm
Shape Square
Raw material Galvanized steel
Support rod thickness (mm) 2mm
Product type Mesh grille galvanized
Height (mm) 30mm
Width (mm) 900mm
Length (mm) 900mm
Shape Square
Raw material Galvanized steel
Support rod thickness (mm) 2mm
