GEOTEXTILE WOVEN SG60/60 5.25X100M BENOR 240G/M²
GEOTEXTILE WOVEN SG60/60 5.25X100M BENOR 240G/M²
| Code | GEO6060 |
| Code | GEO6060 |
| Reference | 21532 |
| Unit | m² |
| Product model | Geotextile fabric |
| Availablility |
Availablility |
| Documents |
Availablility
Become a professional online customer
- ✓ Access to your net prices
- ✓Exclusive online promotions
- ✓ Tracking of your orders, deliveries, and invoices
- ✓ Insight into the currently available stock per branch
- ✓ 1% additional online order discount on top of your net prices
Technical specifications
(Everything you should know)| Product type | Geotextile fabric |
| Weight (g/m²) | 240g |
| Width (m) | 5,25m |
| Length (m) | 100m |
| Raw material | Polypropylene |
| Woven | yes |
| Certificate | BENOR |
| Tensile strength MD (kN/m) | 60 |
| Tensile strength MD (kN/m) norm | EN ISO 10319 |
| Tensile strength CD (kN/m) | 60 |
| Tensile strength CD (kN/m) norm | EN ISO 10319 |
| Water vapour permeability (l/m2*sec) | 23 |
| Water vapour permeability (l/m2*sec) norm | EN ISO 11058 |
| Tension at 2% elongation at break CD (kN/m) | 6 |
| Tension at 2% elongation at break CD (kN/m) norm | EN ISO 10319 |
| Tension at 2% elongation at break MD (kN/m) | 6 |
| Tension at 2% elongation at break MD (kN/m) norm | EN ISO 10319 |
| Tension at 5% elongation at break CD (kN/m) | 13,5 |
| Tension at 5% elongation at break CD (kN/m) norm | EN ISO 10319 |
| Tension at 5% elongation at break MD (kN/m) | 13,5 |
| Tension at 5% elongation at break MD (kN/m) norm | EN ISO 10319 |
| Elongation at max. load CD (%) | 13 |
| Elongation at max. load CD (%) norm | EN ISO 10319 |
| Elongation at max. load MD (%) | 13 |
| Elongation at max. load MD (%) norm | EN ISO 10319 |
| Weight (g/m²) norm | EN ISO 9864 |
| Static perforation resistance CBR (N) | 5600 |
| Static perforation resistance CBR (N) norm | EN ISO 12236 |
| Resistance to dynamic perforation (mm) | 9 |
| Resistance to dynamic perforation (mm) norm | EN ISO 13433 |
| Thickness at 2 kPa (mm) | 1,2mm |
| Thickness at 2 kPa (mm) norm | EN ISO 9863-1 |
| Sand permeability O90 (µm) | 280 |
| Sand permeability O90 (mm) rating | EN ISO 12956 |
| Product type | Geotextile fabric |
| Weight (g/m²) | 240g |
| Width (m) | 5,25m |
| Length (m) | 100m |
| Raw material | Polypropylene |
| Woven | yes |
| Certificate | BENOR |
| Tensile strength MD (kN/m) | 60 |
| Tensile strength MD (kN/m) norm | EN ISO 10319 |
| Tensile strength CD (kN/m) | 60 |
| Tensile strength CD (kN/m) norm | EN ISO 10319 |
| Water vapour permeability (l/m2*sec) | 23 |
| Water vapour permeability (l/m2*sec) norm | EN ISO 11058 |
| Tension at 2% elongation at break CD (kN/m) | 6 |
| Tension at 2% elongation at break CD (kN/m) norm | EN ISO 10319 |
| Tension at 2% elongation at break MD (kN/m) | 6 |
| Tension at 2% elongation at break MD (kN/m) norm | EN ISO 10319 |
| Tension at 5% elongation at break CD (kN/m) | 13,5 |
| Tension at 5% elongation at break CD (kN/m) norm | EN ISO 10319 |
| Tension at 5% elongation at break MD (kN/m) | 13,5 |
| Tension at 5% elongation at break MD (kN/m) norm | EN ISO 10319 |
| Elongation at max. load CD (%) | 13 |
| Elongation at max. load CD (%) norm | EN ISO 10319 |
| Elongation at max. load MD (%) | 13 |
| Elongation at max. load MD (%) norm | EN ISO 10319 |
| Weight (g/m²) norm | EN ISO 9864 |
| Static perforation resistance CBR (N) | 5600 |
| Static perforation resistance CBR (N) norm | EN ISO 12236 |
| Resistance to dynamic perforation (mm) | 9 |
| Resistance to dynamic perforation (mm) norm | EN ISO 13433 |
| Thickness at 2 kPa (mm) | 1,2mm |
| Thickness at 2 kPa (mm) norm | EN ISO 9863-1 |
| Sand permeability O90 (µm) | 280 |
| Sand permeability O90 (mm) rating | EN ISO 12956 |
