CAST IRON GRATE FS=300X300 CO=Ø250 DOUBLE-TOOTH
CAST IRON GRATE FS=300X300 CO=Ø250 DOUBLE-TOOTH
| Code | STZ250R |
| Code | STZ250R |
| Reference | 30391 |
| Unit | pieces |
| Product model | Toothed grate cast iron |
| Availablility |
Availablility
|
| Description |
Cast iron double tongue-and-groove cover and grating with square frame and circular opening. The frame seating and the cover bearing edge are provided with a double tongue-and-groove profile, greased to ensure hydraulic watertightness. Perfect fit on PVC and PP inspection chambers (not on the collar). Provided with a bituminous coating to prevent corrosion. A prefabricated concrete seating ring can also be used to provide the necessary support for the cover. Suitable for pedestrian traffic only. Frame supplied as standard with DRWA marking. |
| Documents |
Availablility
-
Aartselaar
-
Farciennes
-
Geel
-
Hamme
-
Hasselt
-
Herent
-
Herstal
-
Hoogstraten
-
Oostakker
-
Tielt
-
Zedelgem
Cast iron double tongue-and-groove cover and grating with square frame and circular opening. The frame seating and the cover bearing edge are provided with a double tongue-and-groove profile, greased to ensure hydraulic watertightness. Perfect fit on PVC and PP inspection chambers (not on the collar). Provided with a bituminous coating to prevent corrosion. A prefabricated concrete seating ring can also be used to provide the necessary support for the cover. Suitable for pedestrian traffic only. Frame supplied as standard with DRWA marking.
- ✓ Access to your net prices
- ✓Exclusive online promotions
- ✓ Tracking of your orders, deliveries, and invoices
- ✓ Insight into the currently available stock per branch
- ✓ 1% additional online order discount on top of your net prices
Product information
(Well informed)Description
(In detail)Cast iron double tongue-and-groove cover and grating with square frame and circular opening. The frame seating and the cover bearing edge are provided with a double tongue-and-groove profile, greased to ensure hydraulic watertightness.
- Perfect fit on PVC and PP inspection chambers (not on the collar).
- Provided with a bituminous coating to prevent corrosion.
- A prefabricated concrete seating ring can also be used to provide the necessary support for the cover.
- Suitable for pedestrian traffic only.
- Frame supplied as standard with DRWA marking.
Technical specifications
(Everything you should know)| Product type | Toothed grate cast iron |
| Width (mm) | 300mm |
| Load class | A15 |
| Shape | Round |
| Certificate | Uncertified |
| Raw material | Cast iron |
| Height (mm) | 78mm |
| Length (mm) | 300mm |
| Lid properties | Hydraulic seal |
| Clear opening diameter Ø (mm) | 250mm |
| Product type | Toothed grate cast iron |
| Width (mm) | 300mm |
| Load class | A15 |
| Shape | Round |
| Certificate | Uncertified |
| Raw material | Cast iron |
| Height (mm) | 78mm |
| Length (mm) | 300mm |
| Lid properties | Hydraulic seal |
| Clear opening diameter Ø (mm) | 250mm |
