IT PLUS COLUMN BOX 900X600X600MM SLW60

Code	COLUMNBOX90
Code	COLUMNBOX90
Brand	Hewitech
Reference	32991
Unit	pieces
Product model	Infiltration crate
Availablility	Availablility Farciennes Herstal
Description	The IT Plus Columnbox is specifically designed for use in large-scale, engineered applications. The system forms part of a sustainable water management solution and is intended for the storage, conveyance and infiltration of rainwater, whether originating from roofs, roads, car parks or any other paved surface. The height is assembled from two units to form one box with a total height of 600 mm. Full description
Documents	Technical data sheet

Availablility

The IT Plus Columnbox is specifically designed for use in large-scale, engineered applications. The system forms part of a sustainable water management solution and is intended for the storage, conveyance and infiltration of rainwater, whether originating from roofs, roads, car parks or any other paved surface. The height is assembled from two units to form one box with a total height of 600 mm.

Full description

Technical data sheet

Become a professional online customer

✓ Access to your net prices
✓ Exclusive online promotions
✓ Tracking of your orders, deliveries, and invoices
✓ Insight into the currently available stock per branch
✓ 1% additional online order discount on top of your net prices

Accessories
|
Product information
|
Technical specifications
|
Other customers also bought

Accessories

(Selected for you)

IT PLUS COLUMN BOX SIDE PANEL 300X600

Availablility

IT PLUS COLUMNBOX CONNECTOR HALF

Availablility

STACK CONNECTOR IT PLUS COLUMNBOX COMPLETE

Availablility

IT PLUS COLUMN BOX COVER 600X450

Availablility

Product information

(Well informed)

Description

(In detail)

Pros and cons

(According to our consultants)

Extremely high stability (heavy traffic, SLW 60*)
Easy to install (one-man handling)
Significantly reduced transport costs
NEN and TÜV Nord certified
The quality of the polypropylene is checked on a random basis by the relevant certification body
Product quality control during the manufacturing process
German engineering and production
Service life of the polypropylene units: at least 50 years

*SLW 60 = axle load per m²

Technical specifications

(Everything you should know)

Product type	Infiltration crate
Length (mm)	900mm
Height (mm)	600mm
Raw material	Polypropylene
Width (mm)	600mm
Certificate norm	NEN17150:2019
Net volume (L)	304l
Gross volume (L)	320l

Weight per m³ (kg)	48kg
Storage capacity gross (l)	320l
Storage_capacity_net_l	304l
Combined weight (kg)	13,85kg
Weight per m³ (kg)	48kg
Connection options (DN)	125, 160, 200
Maximum depth	3 niveaux, plus sur étude
Empty percentage (%)	95

Product type	Infiltration crate
Length (mm)	900mm
Height (mm)	600mm
Raw material	Polypropylene
Width (mm)	600mm
Certificate norm	NEN17150:2019
Net volume (L)	304l
Gross volume (L)	320l
Weight per m³ (kg)	48kg
Storage capacity gross (l)	320l
Storage_capacity_net_l	304l
Combined weight (kg)	13,85kg
Weight per m³ (kg)	48kg
Connection options (DN)	125, 160, 200
Maximum depth	3 niveaux, plus sur étude
Empty percentage (%)	95
